Product Details:
|
| Anti-Slip: | Yes | Color: | Any |
|---|---|---|---|
| Drainage Holes: | Yes | Durable: | Yes |
| Easy To Install: | Yes | Environmentally Friendly: | Yes |
| Frost Resistant: | Yes | Length: | Tailor Length For The Field Dimension |
| Material: | Polyethylene | Safe For Children: | Yes |
| Size: | 1m X 50m | Usage: | Suitable For All Types Of Artificial Grass |
| Uv Resistance: | Yes | ||
| High Light: | 30mm Artificial Grass Drainage Underlay,Artificial Grass Drainage Underlay For Turf,Turf Shock Pad FIFA Standard |
||
FIFA Standard Foam Shock Pad Underlay For Turf 8mm 15mm 30mm Thickening Drainage Performance Mats Underneath the Grass
Artificial Turf System
1. Proposal without infill:
Ground base + 10 mm TAIHUI shock pad + 35~40 mm artificial turf
Scope of application: Sites for minors using (mainly for primary and secondary school sites).
2. Standard proposal:
Ground base + 10 mm TAIHUI shock pad + 45~55 mm artificial turf + 25~35 kg silica sand + 5 kg TAIHUI Eco-friendly infill
Scope of application: Sites for adult ( mainly for University sites), five-person or seven-person sites for operating.
3. Proposal of FIFA QUALITY PRO:
Ground base + 10 mm TAIHUI shock pad + 50 mm artificial turf + 25~35 kg silica sand + 6 kg TAIHUI Eco-friendly infill.
Applicable scope: Certified professional events sites.
| Comparison between FOAM shock pad and IN-SITU shock pad | ||
| FOAM SHOCK PAD | IN-SITU SHOCK PAD | |
| PRICE | CHEAP | HIGH |
| INSTALLATION COST | CHEAP | HIGH |
| INSTALLATION TIME | VERY FAST | LONGER |
| THICKNESS | THIN | THICK |
| WEIGHT | LIGHT | HEAVY |
| FLATNESS | EVENLY | NOT EVENLY |
| WATER PERMEABILITY | VERY FAST | SLOW |
| RECYCLABLE | EASY | DIFFICULT |
| ENVIRONMENTAL FRIENDLY | YES | NO |
| Product Specifications | ||||||
| Name | Model | Density | Structure | Thickness | Package | Warranty |
| Shock Pad | T3004B/3006K | 30 kg/m3 | 3 layers |
8-30mm
|
1.5m fixed width, one roll in PE bag is one package
|
20 years
|
| T2504B/2506K | 50 kg/m3 | 3 layers | ||||
| T2004B/2006K | 70 kg/m3 | 3 layers | ||||
| T3010G | 30 kg/m3 | 1 layer | ||||
| T2510G | 50 kg/m3 | 1 layer | ||||
| T2010G | 70 kg/m3 | 1 layer | ||||
* Color, Thickness, Density and roll length can all be customized according to the specific pitch.
Product Advantages
Material—The perfect combination of new environmental protection resin and rubber foam, rubber has a strong tensile strength and softness, which ensure the strong elasticity and softness brings sense of comfort at the same time. The UV resistant film brings the long service life for the shock pad which is more environmentally friendly, no odor.
Tensile strength—Three-layer structure and characteristics of rubber makes the shock pad with the strong tensile strength, which will protect the product from deformation and damage during the installation. Tensile strength of one-time forming process product is poor.
Cost—Our shock pad can be installed directly on the water stabilized base, and then covered by artificial turf, which helps to save the cost of concrete or asphalt base.Artificial grass pile height 40 mm filled with quartz sand and granules, whose overall cost is lower than the traditional grass pile 50mm without any infill.
| Our Strength |
| Extensive production experience: we are specialized in shock pad and infill granules for artificial grass for over 10 years. |
| Stable quality and on-time delivery: with our workshop, we can control the quality from raw material to each production process. What's more, we have some stock on the popular items, which means we can meet your urgent need and can ensure the delivery time. |
| Superior production equipment: we own precision machine controlled by computer system and other advanced equipment. Our technicians will do regular scheduled maintenance on these machines to ensure them work well. |
| Customized: the color, length and thickness can all be customized according to the demand of customers. |
| High quality raw material |
| After-sale service: with more than 3,000 pitches around the world, we have earned good reputation among our worldwide partners. |
| Our certificate includes LABOSPORT, SPORTSLABS, SGS. |
| Easy to install and short delivery time |
| Installation support and professional consultant teams |
