Product Details:
|
| Product Name: | Artificial Grass Underlay High Performance Synthetic Turf Shock Proof Pad Mat For Artificial Grass | Sports: | Soccer, Football, Rugby, Hockey, Playground.,etc. |
|---|---|---|---|
| Thickness: | 8.0mm/10.0mm/12.0mm/15.0mm/20.0mm | Size: | 1.5m*50m In Roll |
| Drainage Hole Design: | Four-side Symmetric Inside And Four-side Skew-symmetric Triangle Outside For Water Drainage | Color: | Can Be Customized |
| High Light: | Rugby Field Turf Shock Pads,Turf Shock Pads Artificial Grass,Turf Shock Pads Artificial Grass Underlay |
||
PE Foam Rugby Field Artificial Grass Water Proof Double-Sided Slotted Underlay Shock Absorption 10-30 Mm
Why artificial turf systems need to adopt shock-absorbing pad?
1. The shock pad helps the artificial turf system provide superior resilience and impact resistance to reduce the injury which makes the artificial turf system comparable to the natural grass.
2. With shock pad underneath, the resilience and impact resistance of the artificial system can be maintained for long service life.
Product Innovation Points
| Layered compound proportion 4:6, to maximize shock absorption and minimize vertical deformation. With double-sided synchronous grooved technology, to enhance the water drainage in four directions while reducing the stress. |
| Cutting grooves vertically and horizontally with holes to make sure water drainage in four directions, and installation more even. |
| The perfect combination of rubber and resin, as rubber has strong tensile properties, which can not easily be torn during the installation |
| Adopting a professional ratio of composite process, both to increase the impact of absorption, but also reduce the vertical deformation. |
| The backing film can enhance the breaking force and it is not easy to be damaged during the installation.It also has excellent UV-resistance and Odor-resistance. |
Product Advantages
Material—The perfect combination of new environmental protection resin and rubber foam, rubber has a strong tensile strength and softness, which ensure the strong elasticity and softness brings sense of comfort at the same time. The UV resistant film brings the long service life for the shock pad which is more environmentally friendly, no odor.
Tensile strength—Three-layer structure and characteristics of rubber makes the shock pad with the strong tensile strength, which will protect the product from deformation and damage during the installation. Tensile strength of one-time forming process product is poor.
Cost—Our shock pad can be installed directly on the water stabilized base, and then covered by artificial turf, which helps to save the cost of concrete or asphalt base.Artificial grass pile height 40 mm filled with quartz sand and granules, whose overall cost is lower than the traditional grass pile 50mm without any infill.
| Product Specifications | |
| Model: | T3010G |
| Thickness: | 8-30 mm |
| Material: | New environmental friendly PE foam |
| Density: | 30~90 kg/m3 |
| Color: | Black and blue or other colors |
| Features: | Closed cell foam, double-sided grooved |
| Size: | W1.5m * L50m or tailored length |
| Production time: | Normally within 10 days |
| Package: | Recyclable PE bag |
Why Should You Choose Us?
1. We offer outstanding products
2. Choose us you can get
3. Please Note
Trust we will support you by excellent quality and friendly price. Our products will make your artificial turf pitch fantastic!
Welcome for any inquiry.
